Baffles allow the circulation of the polymer preparation through a series of compartments. This ensures the optimum reaction time in each compartment and, a continuous concentration level, thereby avoiding any preferential route between the preparation compartment and the final dosing solution compartment.
The POLYPACK system is automated by the control panel connected to the ultrasonic level detector located above the dosing solution compartment. As soon as the solution in the dosing compartment reaches “low level”, the detector activates the opening of the water feed electrovalve and the start-up of the dry feeder. The water meter controls the flow continuously. As soon as the “high level” is reached, the process cycle stops, although the mixers (one, two or three according the model) continue to operate. The POLYPACK unit provides automatic and continuous preparation of the polymer solution using a constant and uniform quality, resulting from:
- One two-impeller mixer located in the preparation compartment (single impeller in the maturation compartment)
- Optimized maturation cycles
By fitting with an optional dilution unit, the main solution can then be diluted.
Discover the key benefits of using our POLYPACK:
- Avoid the need for manual operations – Prevent dosing errors, operation stops.
- Standardization of the obtained polymer – Concentration, maturation time, homogeneity.
- High efficiency mixers – Provide a low flow mixing for a homogeneous flocculant polymerization without mechanical deterioration.
- Optimized process – Visual access to the process and alarms, fieldbus distributed control (optional) provides informative and easy to access equipment and status application updates, controlled costs. Intelligent system that feeds the process when needed, regulated by an ultrasonic level switch.
- Reliability and Robustness in Any Environment.
- Option DUAL - Two-in-one solution, to prepare powder or liquid polymers. Ideal solution for wastewater plants located in areas subject to population changes, such as tourist areas, or locations subject to rainy season that have to adapt their process according to the population equivalent or the season.
- Compact design – For easy transport and relocation.
